Description
VIBROFILTR Sound Deadening Mats 2 mm 350 X 500 mm (Box of 20)
Number of sheets in a collective packaging: 20 pcs. / 3.5 m2
Vibrofiltr 2.0
Self-adhesive professional anti-vibration mat for damping vibrations, noise and resonance of acoustic elements of car body and upholstery, yachts, machines and industrial equipment, computer equipment housings, RTV or home appliances – price per collective package: 20 sheets with dimensions of 350×500 mm (3.5 m2 ), thickness of the 2.0 mm mat, thickness of the aluminum film 100 micrometres (0.1 mm).
Vibrofiltr 2.0 is the most versatile and also the most popular damping material Vibtofiltr NP series (Noise Protection) among European car audio equipment installers and companies dealing in professional vehicle silencing. Due to the above-average high mechanical loss factor (0.38) at moderate weight, this material can be used on any of the body parts and upholstery of the vehicle from the floor to the roof. While observing all the rules of proper and reliable assembly, the achieved results can often exceed all expectations.
BASIC PARAMETERS:
self-adhesive mat for damping vibrations, noise and acoustic resonances
material: composite based on high-quality butyl rubber (butyl rubber) and polymers reinforced with aluminum foil
sheet thickness: 2.0 mm +/- 0.1 mm
thickness of aluminum foil: 0.1 mm (100 μm)
dimensions of 1 sheet: 350×500 mm
area of 1 sheet: 0.175 m2
quantity in a package: 20 sheets / 3.50 m2
Weight: 12.39 kg / (3.54 kg / m2)
MLF (mechanical loss coefficient) – vibration suppression efficiency (more = better): 0.38
recommended installation temperature: above + 15ºC
temperature range of use and operation: -50ºC to + 160ºC
strength of material binding to the surface of the metal: not less than 6 N / cm2
high flexibility and high efficiency in a wide range of temperatures
the stability of the viscous butyl polymer layer with a temperature effect of + 90 ° C in 24 hours: delamination and creep do not occur
high adhesion to the substrate with a maximum achieved after a dozen or so to several dozen hours after sticking (depending on the temperature), self-vulcanization
product with anti-corrosion and sealing properties, waterproof, does not contain bitumen additives (without tar and asphalt)
product non-toxic, non-staining, does not emit unpleasant odours.
